产品详情
物性表下载
咨询技术提问

螺杆直径： 21.7~35.0 毫米

长径比：其他

电机类型：交流变频

切粒方式：拉条切粒

适合产品： TPU,填充母粒,色母粒

本机适合工程塑胶、改性塑胶、废旧塑胶、色母粒的混炼加工实验。具有均质、塑化着色、填充改性等功能。

Introduction: This machine is suitable for mixing and processing experiments of engineering plastics, modified plastics, waste plastics and masterbatches. It has homogeneous, plastic coloring, filling modification functions.

工作原理

本机通过加热、混合，剪切、塑化、压实排气作用下，物料塑化成均匀的熔体，并在双螺杆的挤压下，通过机头挤出圆形的条状料，经冷却水槽水冷后或者风冷后，再经切粒机切粒，得到塑胶粒料。

Working principle: Under the action of heating, mixing, shearing, plasticizing and compacting the exhaust, the material is plastified into a uniform melt, and extruded under the twin-screw and extruded through the nose into round strips. The long strips after being cooled by water in the cooling water tank or after being air-cooled, then pelletized by a pelletizer to obtain plastic pellets.

技术参数(Technical Parameters)：

型号

Model No.

XH-433-25

控制系统

Control system

PLC控制

PLC control

产量（kg)

Capacity

约1-10kg/h根据工艺配方

1-10kg/h(decide by formula )

螺杆直径

Screw diameter

21.7mm或指定

21.7mm or customized

长径比

L/D

1：40

螺杆转速rpm

Screw speed

0-300

冷却装置

Cooling device

风冷/水冷（可选配）

Air/water cooling (optional)

风机

Fan

1/4HP

切粒机

Cutting device

切粒机Granulator

电源

Power Supply

3∮，AC380

特殊型号可根据客户要求设计制作。

Special extruder can be designed and fabricated adapted to the requirements of customers.
